Description
Time to Level Up!
The Cannondale Trail is your first-class upgrade to next-level mountain biking—engineered for fun by a brand trusted by Champions.
Model Description
Trail 1 blends Cannondale’s 50 years of alloy expertise with modern trail capability. The SmartForm C3 alloy frame delivers a ride that’s light and responsive, while the SR Suntour XCM35 fork with 100mm travel (80mm on XS and Small sizes) takes care of the bumps so you can focus on the fun. Shimano’s CUES 10-speed drivetrain makes shifting smooth and reliable, and Tektro hydraulic disc brakes bring confidence to every descent. With a 130mm dropper post for instant seat adjustments, Trail 1 is proof that decades of innovation can deliver first-class performance, one ride at a time.
What it’s for
Trail riding, light commuting, bopping around town, and having a blast.
Highlights
- A lightweight, durable SmartForm C3 Alloy frame
- 29” wheels on the larger sizes, 27.5” wheels on XS and Small for the best blend of fit and speed
- Bump-eating SR Suntour XCM35 Boost fork with 100mm of travel (80mm on XS and Small sizes)
- Shimano CUES U6000 10-speed shifting – wide range gearing with the simplicity of a single front chainring
- A hidden kickstand mount, plus mounts for a rack and fenders, offer true do-it-all versatility
- Platform Trail
- Model Name Trail 1
- Model Code C26055U
Frameset
- Frame Trail, SmartForm C3 Alloy, 142x12mm, SAVE, 1-1/8″ headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, KickFlip hidden 18mm 2-bolt kickstand mount, BSA-73, 27.5″ wheels (XS, S) / 29″ wheels (M, L, XL)
- Fork SR Suntour XCM Boost, coil, 100mm travel, 46mm offset (29″), 80mm travel, 42mm offset (27.5″)
- Headset Semi-Integrated, 1-1/8″
Drivetrain
- Rear Derailleur Shimano CUES U6000
- Shifters Shimano CUES U6000, 10-speed
- Chain KMC X10, 10-speed
- Crank Prowheel, Charm 30T
- Rear Cogs Shimano CUES, 11-48, 10-speed
- Bottom Bracket ProWheel, square taper
Brakes
- Brakes Tektro M275 hydraulic disc, 160/160mm rotors
- Brake Levers Tektro hydraulic disc
Wheels
- Front Hub Shimano TC500, 15x110mm
- Rear Hub Shimano TC500, 12x142mm
- Rims WTB SX19, 32h
- Spokes Stainless Steel, 14g
- Tire Size 2.25
- Wheel Size 27.5/29
- Tires WTB Ranger, 27.5×2.25″ (XS, S) / 29×2.25″ (M, L, XL)
- Front Tire WTB Ranger, 27.5×2.25″ (XS, S) / 29×2.25″ (M, L, XL)
- Rear Tire WTB Ranger, 27.5×2.25″ (XS, S) / 29×2.25″ (M, L, XL)
Components
- Handlebar Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm
- Stem Cannondale 4, 6061 Alloy, 31.8, 6°
- Grips Cannondale
- Saddle Cannondale Trail
- Seatpost JD Dropper, internal routing, 31.6, 130mm
Please note that, based on component availability and other factors, specifications are subject to change without notice.
